PESD15VS5UD,115
| Manufacturer | |
| Description | TVS Diode Arrays 15V 5X ESD ARRAY ESD Suppressor Diode Arrays 30KV 6-Pin TSOP T/R TVS DIODE 15VWM 33VC 6TSOP TVS Diode Uni-Directional PESD15VS5UD,115 Quint 33V, 200W, TSOP 6-Pin |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 568-4144-1 | Part # Aliases | PESD15VS5UD T/R |
| Product Category | TVS Diode Arrays | Standard Package | 3,000 |
| Factory Pack Quantity | 3000 | Standard Package Name | TSOP |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| ESD Protection | 30@Contact Disc/10@HBM | ||
Electrical
| Channels | 5 Channels | Capacitance | 32 pF |
| Voltage Rating | 15 | Current - Surge | 5 A |
| Voltage - Supply | 15V (Max) | Number of Elements | 5 |
| Power - Peak Pulse | 200W | Voltage - Clamping | 33V |
| Voltage - Breakdown | 17V | Power Line Protection | No |
| Voltage - Supply (Min) | 15 V | Capacitance @ Frequency | 60pF @ 1MHz |
| Unidirectional Channels | 5 | Current - Reverse Leakage @ Vr | 0.015 |
| Current - Peak Pulse (10/1000us) | 6A (8/20µs) | ||
Mechanical
| Width | 1.7(Max) | Packaging | Tape and Reel |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | SC-74, SOT-457 |
| Length - Overall | 3.1(Max) | Package Quantity | TSOP |
| Size / Dimension | 3 mm W x 3.1 mm L x 1.1 mm H | Termination Style | SMD/SMT |
| Number of Positions | 6 | Shell Size - Insert | 1(Max) |
| Supplier Device Package | 6-TSOP | ||
Product Info
| Type | Diode Arrays | Series | PESDxS5UD |
| Polarity | Unidirectional | Applications | General Purpose |
| Configuration | Quint | Port Direction | Uni-Directional |
| Printed Circuit Board | 6 | ||
Environmental
| Operating Temperature | -65°C ~ 150°C | ||
