PESD12VS4UD,115
| Manufacturer | |
| Description | TVS Diode Arrays DIODE ARRAY ESD TVS DIODE 12VWM 24VC 6TSOP TVS Diode Uni-Directional PESD12VS4UD,115 Quad 24V, 200W, TSOP 6-Pin ESD Suppressor TVS 30KV 6-Pin TSOP T/R PESD12VS4UD@115 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 568-4263-1 | Part # Aliases | PESD12VS4UD T/R |
| Product Category | TVS Diode Arrays | Standard Package | 3,000 |
| Factory Pack Quantity | 3000 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Rad Hardened | No |
Electrical
| Channels | 4 Channels | Capacitance | 73 pF |
| Voltage Rating | 12V | Current - Surge | 10 A |
| Voltage - Supply | 12V (Max) | Current - Leakage | 0.015uA |
| Voltage - Working | 12V | Number of Elements | 4 |
| Power - Peak Pulse | 200W | Voltage - Clamping | 24V |
| Current - Trip (It) | 1 mA | Voltage - Breakdown | 12.5V |
| Power Line Protection | No | Voltage - Supply (Min) | 12 V |
| Capacitance @ Frequency | 73pF @ 1MHz | Unidirectional Channels | 4 |
| Current - Peak Pulse (8/20us) | 10 A | Current - Peak Pulse (10/1000us) | 10A (8/20µs) |
| Voltage - Reverse Standoff (Typ) | 12 V | ||
Mechanical
| Depth | 1.7 mm | Height | 1 mm |
| Packaging | Tape & Reel (TR) | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | SC-74, SOT-457 |
| Package Cooled | SC-74 | Locking Feature | TVS |
| Length - Overall | 3.1 mm | Size / Dimension | 3 mm W x 3.1 mm L x 1.1 mm H |
| Termination Style | SMD/SMT | Number of Positions | 6 |
| Supplier Device Package | 6-TSOP | ||
Product Info
| Type | Zener | Series | PESDxS4UD |
| Polarity | Unidirectional | Applications | General Purpose |
| Configuration | Quad | Port Direction | Uni-Directional |
Environmental
| Operating Temperature | -65°C ~ 150°C | Operating Temperature - Junction | 150C |
