LPC2146FBD64,557
| Manufacturer | |
| Description | MCU 16-bit/32-bit LPC2000 ARM7TDMI-S RISC 256KB Flash 3.3V 64-Pin LQFP Tray MCU 16-bit/32-bit LPC2100 ARM7TDMI-S RISC 256KB Flash 3.3V 64-Pin LQFP Tray IC ARM7 MCU FLASH 256K 64LQFP ARM Microcontrollers - MCU 256K FL/32K RAM 10BIT ADC/DAC |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | USB MCU | Tradename | LPC |
| Standard Package | Trays | Factory Pack Quantity | 800 |
| Standard Package Name | QFP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Approval Agency | No | ||
Electrical
| Speed | 60 MHz | RAM Size | 40 KB |
| Core Size | 16/32-Bit | Core Type | ARM7TDMI-S |
| Interface | I2C/SPI/SSP/UART/USB | Clock Rate | 60 MHz |
| Memory Size | 42 kB | Memory Type | SRAM |
| Number of I/O | 45 | Voltage - I/O | 3.3 V |
| Number of Bits | 10/10 | Voltage Rating | 3 |
| Watchdog Timer | 1 | Data Converters | A/D 14x10b; D/A 1x10b |
| Oscillator Type | Internal | Serial Protocol | 2 |
| Voltage - Supply | 3.3 V | Resolution (Bits) | 10 bit |
| Program Memory Size | 256 KB | Program Memory Type | Flash |
| Number of ADCs / DACs | 14/14 | Voltage - Supply (Min) | 3.6 |
| Power Dissipation (Max) | 1500 mW | Number of Counter/Timers | 2 x 32 bit |
| Voltage - Supply, Analog | 3.3 V | Voltage - Supply (Vcc/Vdd) | 3 V ~ 3.6 V |
Mechanical
| Width | 10.1(Max) | Packaging | Tray |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 64LQFP |
| Length - Overall | 10.1(Max) | Package Quantity | LQFP |
| Number of Positions | 64 | Shell Size - Insert | 1.4(Max) |
| Number of Cores/Bus Width | 16|32 Bit | ||
Product Info
| SPI | 1 | USB | 1 |
| Series | LPC2146 | Protocol | 2 |
| On-Chip RAM | 2(14-chx10-bit) | Peripherals | Brown-out Detect/Reset, DMA, POR, PWM, WDT |
| Architecture | RISC | Connectivity | I²C, Microwire, SPI, SSI, SSP, UART/USART, USB |
| Manufacturer | NXP Semiconductors | Core Processor | ARM7® |
| Number of Timers | 2 | RF Family/Standard | LPC2000 |
| DigiKey Programmable | Yes | Printed Circuit Board | 64 |
| Number of Inputs and Type | 45 I/O | ||
Environmental
| Operating Temperature | -40 to 85 °C | ||
