LM75AD,118
| Manufacturer | |
| Description | Temp Sensor Digital Serial (2-Wire, I2C) 8-Pin SO Tube Temp Sensor Digital Serial (2-Wire, I2C) 8-Pin SO T/R IC TEMP SENSOR DIGITAL 8-SOIC Board Mount Temperature Sensors I2C LOCAL +/- 2OC TS LM75AD@118 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 568-10295-1 | Part # Aliases | LM75AD-T |
| Product Category | Board Mount Temperature Sensors | Standard Package | Tape & Reel |
| Factory Pack Quantity | 2500 | Standard Package Name | SOIC |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | ||
Electrical
| Accuracy | ±3(Max) °C | Interface | Serial (2-Wire, I2C) |
| Tolerance | ±3°C(Max) | Output Fan | Yes |
| Resolution | 11 Bit | Output Type | Digital |
| Sensor Type | Internal | Number of Bits | 11 bit |
| Voltage Rating | 2.8 | Current - Output | 10 mA |
| Voltage - Supply | 2.8 to 5.5 V | Digital I/O Lines | 2-Wire, I2C, SMBus |
| Voltage - Supply (Min) | 2.8 V | ||
Mechanical
| Width | 4(Max) | Packaging | Tape and Reel |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 8SO |
| Package Cooled | SO | Length - Overall | 5(Max) |
| Package Quantity | SO | Number of Positions | 8 |
| Shell Size - Insert | 1.45(Max) | Supplier Device Package | 8-SO |
Product Info
| Series | LM75A | DELETED | Compliant |
| Function | Temp Sensor | Shutdown | Yes |
| Topology | ADC (Sigma Delta), Comparator, Oscillator, Register Bank | Output Alarm | Yes |
| Configuration | Local | Printed Circuit Board | 8 |
Environmental
| Sensing Temperature | -55°C ~ 125°C | Operating Temperature | -55 °C |
| Switching Temperature | Programmable | Temperature Coefficient | -55°C ~ 125°C |
| Operating Temperature - Junction | 125C | ||
