NRF8002-R1Q32-R7
| Manufacturer | |
| Description | SINGLE-CHIP BLUETOOTH LOW ENER RF System on a Chip - SoC Single chip BT Low Energy device NRF8002-R1Q32-R7 IC BLUETOOTH PROXIMITY 32QFN SINGLE CHIP BT LE PROXIMITY |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 1,500 | Factory Pack Quantity | 1500 |
Compliance
| RoHS | RoHS Compliant | Automotive | NO |
| Leadfree Defin | RoHS-conform | ||
Electrical
| Frequency | 2402 MHz to 2480 MHz | Interface | 2-Wire, UART |
| Memory Type | RAM | Sensitivity | - 87 dBm |
| Antenna Type | N Y/N | Output Power | 4 dBm |
| Data Interface | PCB, Surface Mount | Power - Output | 0dBm |
| Data Rate (Max) | 1 Mbps | Current - Supply | 14.5 mA |
| Voltage - Supply | 3 V | Current - Output 1 | 14.5mA |
| Current - Receiving | 14.5mA | Current - Transmitting | 14.5mA |
| Current - Supply (Main IC) | 12.5 mA | ||
Mechanical
| Width | 5 mm | Height | 0.85 mm |
| Length | 5 mm | Weight | 0.0635 g |
| Packaging | Reel | Connector Type | PCB, Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | QFN-32 |
| Antenna Connector | PCB, Surface Mount | Number of Cores/Bus Width | 8 bit |
Product Info
| Type | Bluetooth | Series | nRF8002 |
| On-Chip RAM | No | Applications | RKE |
| Manufacturer | Nordic Semiconductor | Number of Timers | 2 |
| Modulation or Protocol | Bluetooth v4.0, Low Energy | ||
Environmental
| Operating Temperature | - 25 C to + 70 C | ||
