NRF51822-QFAB-R7
| Manufacturer | |
| Description | BLE/2.4GHZ RF SOC WITH 128K FL RF System on a Chip - SoC 2.4GHz BT low Energy 128KB Flash 16KB Ram IC SOC 2.4GHZ 128K FLASH 48QFN |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 1490-1032-2 | Standard Package | 1,000 |
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Core Type | ARM Cortex M0 | Frequency | 2.4 GHz |
| Interface | 2-Wire, SPI, UART | Memory Size | 16 kB |
| Memory Type | RAM | Sensitivity | - 92.5 dBm |
| Output Power | + 4 dBm to - 20 dBm | Data Interface | PCB, Surface Mount |
| Power - Output | 4dBm | Data Rate (Max) | 250 Kbps |
| Current - Supply | 9.5 mA | Voltage - Supply | 1.8 V to 3.6 V |
| Resolution (Bits) | 10 bit | Current - Receiving | 13.4mA |
| Program Memory Size | 128 kB | Program Memory Type | Flash |
| Current - Transmitting | 16mA | Current - Supply (Main IC) | 6.3 mA |
| Number of Bits per Element | 10 bit | ||
Mechanical
| Packaging | Reel | Mounting Style | SMD/SMT |
| Package / Case | QFN-48 | Antenna Connector | PCB, Surface Mount |
| Number of Cores/Bus Width | 32 bit | ||
Product Info
| Type | Bluetooth | Series | nRF51822 |
| On-Chip RAM | Yes | Applications | General Purpose |
| Manufacturer | Nordic Semiconductor | Number of Timers | 2 |
| Modulation or Protocol | Bluetooth v4.0, Low Energy | ||
Environmental
| Operating Temperature | -25°C ~ 75°C | ||
