FBA06A12H1BX

Manufacturer	MinebeaMitsumi Inc.
Description	FAN 12VDC W 60MM HYDROWAVE
Category	Hardware and Thermal SolutionsDC FansBlowers

对参数有疑问？问 AI 助手

Business

Lead Time	365 Days	Subcategory	Blowers and Fans
Standard Package	100

Compliance

RoHS

Lead free / RoHS Compliant

Electrical

Noise	32 dB	Power (Watts)	1.86W
Voltage Range	7 ~ 13.8VDC	Voltage Rating	12VDC
Current Rating (Max)	0.155A

Mechanical

RPM	4200 RPM	Weight	0.198 lb (89.81g)
Air Flow	19.1 CFM (0.541m³/min)	Fan Type	Tubeaxial
Termination	3 Wire Leads	Bearing Type	Hydro-wave (HWB)
Static Pressure	0.204 in H2O (51.0 Pa)	Size / Dimension	Square - 60mm L x 60mm H x 25.5mm W

Product Info

Features

Speed Sensor (Tach)

Industry Aliases

FBA06A 12H1BX

Environmental

Rated Life

50000 hrs @ 40°C

Operating Temperature

14 ~ 158°F (-10 ~ 70°C)

Documents & Media

PDF Document

FB Series Part Number Guide
