CLSD001B
| Manufacturer | |
| Description | Low and High Current LED Driver - 10W to 20W Power Rating LED SUPPLY CC AC/DC 8.3-25V 1.2A LED DRIVER, AC-DC, 1.2A, 25V |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | P14883 | Standard Package | 1 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Supplier Unconfirmed |
| Tariff No | 85423990 | Rad Hardened | No |
| Approval Agency | CE, CSA, EN, UL | ||
Electrical
| Dimming | Analog | Efficiency | 85% |
| Range deg/s | :NMB LIGHTING - CLSD Series | Power (Watts) | 20W |
| Voltage Rating | 90 | Current - Output | 1.2A |
| Number of Outputs | 1 | LED Driver Channels | :- |
| Voltage - Isolation | 1.5kV (1500V) | Voltage - Input (Min) | 8.3 ~ 25 V |
| Voltage - Output (Max) | :25V | Voltage - Supply (Min) | 90 V |
| Voltage - Continuous Operating (Max) (MCOV) | :277V | ||
Mechanical
| Depth | :33mm | Length | :155mm |
| Weight | 1.1 lbs (499g) | Mounting Type | Chassis Mount |
| Size / Dimension | 6.10" L x 2.17" W x 1.30" H (155.0mm x 55.0mm x 33.0mm) | Termination Style | Wire Leads |
| Number of Positions | 6 | ||
Product Info
| Type | Constant Current | Features | OTP, OVP, SCP |
| Topology | AC DC Converter | Applications | :Lighting |
Environmental
| Ratings | IP66 | Operating Temperature | -20°C ~ 60°C |
| Operating Temperature - Junction | 60C | ||
