M2012LL1W01
| Manufacturer | |
| Description | Toggle Switches ON-NONE-ON SPDT Switch Toggle ON None ON SPDT Locking Lever Solder Lug 6A 250VAC 30VDC Panel Mount with Threads SWITCH TOGGLE SPDT 6A 125V SWITCH, TOGGLE, SPDT, 6A, 125VAC SWITCH,TOGGLE,SUBMINIATURE,LOCKINGLEVER,THREADEDBUSHINGW/SOLDERLUGTERMINAL |
| Category |
对参数有疑问？问 AI 助手
Business
| Part # Aliases | M-2012NLS1 | Product Category | Toggle Switches |
| Standard Package | 100 | ||
Compliance
| RoHS | RoHS Compliant By Exemption | EU RoHS | Compliant |
| Tariff No | 85365080 | ||
Electrical
| Circuit | SPDT | Operation | OnNoneOn |
| Voltage Rating | 125 V, 250 V | Number of Poles | 1 |
| Switch Function | ON - NONE - ON | Voltage - Rated AC | 250V VAC |
| Dielectric Strength | 1500VAC | Current Rating (Max) | 6 A |
| Current - Max/Contact | :6A | Voltage - Input (Min) | 250 |
| Switch Function/Rating | ON None ON | Connector - Voltage Input | :Solder |
| Voltage - Supply (Vcc/Vdd) | :30V | Voltage - DC Spark Over (Nom) | 30V VDC |
| Voltage - Rated AC (Phase to Ground/Neutral) | :125V | ||
Mechanical
| Depth | 8 | Height | 40.1 |
| Weight | 0 | Packaging | Bulk |
| Body Finish | Miniature | Termination | SolderLugs |
| Contact Form | SPDT | Actuator Type | Lever |
| Mounting Type | Panel Mount with Threads | Terminal Type | Solder Lug |
| Bushing Thread | 1/4-40 | Contact Finish | Silver |
| Mounting Style | Panel | Actuator Length | 16.50mm |
| Contact Material | Silver Alloy | Length - Overall | 13 |
| Actuator Material | Brass, Chrome Plated | Termination Style | Solder Lug |
| Actuator Style/Size | Locking Lever | Number of Positions | 2 |
| Bushing, Grommet Type | 1/4-40 | Mounting Hole Diameter | 0.256In. |
| Switch Actuation Level | SPDT | Contact Layout, Typical | :SPDT |
| Panel Cutout Dimensions | Circular - 6.50mm Dia | ||
Product Info
| Type | Miniature | Series | M |
| Features | Epoxy Sealed Terminals | Illumination | Not Illuminated |
| Electrical Life | 25,000 Cycles | ||
Environmental
| Seal Rating | Epoxy | Mechanical Life | 50000 |
| Operating Temperature | -30°C ~ 85°C | Operating Temperature - Junction | 85C |
