LB25WGG01-28-FJ
| Manufacturer | |
| Description | STD SIZE PUSHBUTTON/ILLUMINATED/ Pushbutton Switches STD SIZE PUSHBUTTON ILLUMINATED/IP RATED SWITCH PUSHBUTTON DPDT 0.4VA 28V |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 1 | ||
Compliance
| RoHS | RoHS Compliant | Material Flammability Rating | UL 94 V-0 |
Electrical
| Circuit | DPDT | Optic Size | T-1 Bi-pin |
| Power - Rated | 0.4 VA | Voltage Rating | 28 V |
| Switch Function | ON - (ON) | Current Rating (Max) | 0.4VA (AC/DC) |
| Illumination Voltage (Nominal) | 28 VAC | ||
Mechanical
| Packaging | Bulk | Contact Form | DPDT |
| Actuator Type | Round | Mounting Type | Panel Mount, Front |
| Contact Finish | Gold | Mounting Style | Panel |
| Housing Material | Polyamide, Glass Fiber Reinforced | Termination Style | Solder Lug |
| Illumination Color | Clear | Color - Actuator/Cap | Green |
| Panel Cutout Dimensions | Circular - 22.00mm Dia | Illumination Type, Color | Incandescent, Green |
Product Info
| Type | Standard, Illuminated | Series | * |
| Illumination | LED | Electrical Life | 100,000 Cycles |
Environmental
| Seal Rating | Epoxy | Mechanical Life | 1,000,000 Cycles |
| Ingress Protection | IP65 - Dust Tight, Water Resistant | Operating Temperature | -25°C ~ 50°C |
Documents & Media
PDF Document
Similar Parts
AT9410
