CKM13EFW01-001
| Manufacturer | |
| Description | Keylock Switches ON-OFF-ON 3A LUG FLT KY#01 RMVE 1POS 16MM SWITCH KEYLOCK 16MM KEYCODE 001 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | Q2208572 | Part # Aliases | CK-M13EFS1-UNC-001 |
| Product Category | Keylock Switches | Standard Package | 1 |
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Circuit | SPDT | Voltage Rating | 250 V |
| Switch Function | ON - OFF - ON | Current Rating (Max) | 3 A |
| Contact Rating @ Voltage | 3 A at 250 V | ||
Mechanical
| Contact Form | SPDT | Actuator Type | Flat Key |
| Mounting Type | Panel Mount | Angle of Throw | 45° |
| Contact Finish | Silver | Housing Material | Polybutylene Terephthalate, Glass Fiber Reinforced |
| Termination Style | Solder Lug | Number of Positions | 3 |
| Bushing, Grommet Type | 16 mm | ||
Product Info
| Key Type | Flat | Other Specifications | 45 deg |
| Key Removable Positions | 2 only | ||
