NHD-3.5-320240MF-ATXL#-1
| Manufacturer | |
| Description | TFT Displays & Accessories 3.5 320 x 240 DPI 76.9 x 63.8 x 3.3 LCD DISP TFT 3.5" 320X240 B/L 3.5in Diagonal 320x240Pixels Parallel LED Backlight 3.3V Power Supply 54-Pin |
| Category |
Business
| Product | Displays | Other Names | NHD35320240MFATXL1 |
| Product Category | TFT Displays & Accessories | Standard Package | 50 |
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Backlight | White LED | Interface | 24 bit Digital RGB |
| Resolution | 320 x 240 | Display Type | TFT |
| Voltage - Supply | 3.3 V | Current - Average Rectified (Io) | 8.6 mA |
Mechanical
| Size | 76.9 mm x 63.9 mm x 2.8 mm | Packaging | Bulk |
| Background Color | Normally Black | ||
Product Info
| Dot Pixels | 320 x 240 (QVGA) | Touchscreen | No |
| Display Mode | Transmissive | Viewing Area | 70.08 mm x 52.96 mm |
| Diagonal Screen Size | 3.5 in | Other Specifications | No Touch Panel |
Environmental
| Operating Temperature | - 20 C to + 70 C | ||
Documents & Media
Similar Parts
046240054005800+
avx / elco
Conn FFC/FPC Connector SKT 54 POS 0.5mm Solder RA SMD T/R CONN FPC ONE-TOUCH LCK .5MM 54 FFC & FPC Connectors 54P ZIF RIGHT ANGLE SMT
NHD-COG14-36
Newhaven Display
TFT Displays & Accessories Various Pitch SMT-thru-hole adptr ADAPTER SMT TO 2.54MM THRU-HOLE Various Pitch SMT Adapter To 2.54mm Thru-Holes
NHDEV DEVELOPMENT BOARD
Newhaven Display
Display Development Tools LCD Development Brd 100 mm x 95 mm BOARD DEV LCD COG TFT 100X95MM
0512965494
Molex
Conn FFC/FPC Connector SKT 54 POS 0.5mm Solder RA SMD Embossed T/R CONN FFC/FPC 54POS ZIF .5MM SMD
NHD-3.5-320240MF-20
Newhaven Display Intl
BOARD CTRLR FOR NHDEV 3.5 TFT
S5U13781R00C10M
Epson Electronics America Inc-Semiconductor Div
BOARD EVAL BOOSTERPACK S1D13781 Display Development Tools S1D13781 BoosterPack LCDC Development Pkg
NHD-3.5-320240MF-VIDEO BOARD V1.1
Newhaven Display Intl
BOARD DEMO 3.5 SVIDEO 12V
(SN).jpg&w=3840&q=75)
B3B-XH-A (LF)(SN)(P)
