88-00151-00
| Manufacturer | |
| Description | WiFi / 802.11モジュール SN8200 Wifi Network Controller Module Wi-Fi Network Controller Support WICED 62-Pin SMD WI-FI NETWORK CONTROLLER MODULE WiFi / 802.11 Modules SN8200 Wifi Network Controller Module Wi-Fi Network Controller Module |
| Category |
对参数有疑问？问 AI 助手
Business
| Tradename | SyNode | Other Names | 490-5884-1 |
| Standard Package | 400 | Standard Package Name | SMD |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Data Rate | 11 Mbps, 54 Mbps | Frequency | 2.4GHz ~ 2.4835GHz |
| Interface | I2C, SPI, UART | Modulation | CCK, DSSS |
| Power - Max | 18 dBm | Sensitivity | -96dBm |
| Data Interface | PCB, Surface Mount | Power - Output | 20dBm |
| Data Rate (Max) | 54Mbps | Current - Supply | 110 mA |
| Voltage - Supply | 2 V ~ 3.6 V | Current - Output 1 | 370mA |
| Current - Receiving | 110mA | Current - Transmitting | 370mA |
| Current - Supply (Main IC) | 370 mA | Frequency Bands (Low / High) | 2.4 GHz |
Mechanical
| Width | 19.4 | Packaging | Tape & Reel (TR) |
| Mounting Type | Surface Mount | Connector Type | PCB, Surface Mount |
| Package / Case | Module | Length - Overall | 30.5 |
| Package Quantity | SMD | Size / Dimension | 30.5 mm x 19.4 mm x 2.8 mm |
| Antenna Connector | On-Board, Chip | Number of Positions | 62 |
| Shell Size - Insert | 2.8 | ||
Product Info
| Series | SN8200 | Protocol | 802.11 b/g/n |
| Applications | General Purpose | Printed Circuit Board | 62 |
| Modulation or Protocol | 802.11 b/g/n | ||
Environmental
| Operating Temperature | -30°C ~ 85°C | ||
Documents & Media
PDF Document
