NTA1205MC
| Manufacturer | |
| Description | ISOLATED 1W DUAL OUTPUT SM DC/DC CONVERTERS Module DC-DC 2-OUT 5V/-5V 0.1A/-0.1A 1W 10-Pin SMD Tube CONV DC/DC SM 1W 12VIN 5V DL 1KV DC/DC converter,12Vin,+/-5Vout 100mA 1W DC/DC Converters 1W DUAL OUT 12-05VDC Dual Output CONVERTER, DC/DC, SMD, 1W, +/-5V DC/DCconverter,12Vin,+/-5Vout100mA1W Murata Power Solutions NTA 系列 隔离式直流-直流转换器 , ±5V dc输出, ±0.1A输出 |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 25 | Product | Isolated |
| Unit Pack | 25 | Other Names | 811-1669-5 |
| Product Category | DC/DC Converters | Standard Package | Bulk |
| Factory Pack Quantity | 25 | Standard Package Name | SMD |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85044030 |
| Approval Agency | :CECC 00802 | Material Flammability Rating | :UL94V-0 |
Electrical
| Isolation | Isolated | Efficiency | 69% |
| Power - Max | 1W | Output Power | 1 W |
| Power - Rated | 1W | Converter Type | :Isolated POL |
| Voltage Rating | 5|-5 V | Voltage - Input | 12 V |
| Current - Output | 0.1|-0.1 A | Voltage - Supply | :12V |
| Number of Outputs | 2 | Current - Output 2 | :100mA |
| Power (Watts) - Max | 1W | Voltage - Isolation | 1kV (1000V) |
| Voltage - Input (Min) | 5V | DC Voltage - Input (Max) | :13.2V |
| Current - Output / Channel | +/- 100 mA | ||
Mechanical
| Depth | 7.7mm | Width | 6.35mm |
| Height | 5.95 mm | Length | 15.24mm |
| Weight | 0.053969 oz | Packaging | Tube |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Package / Case | 18-SMD Module (10 Leads) | Length - Overall | 15.24 |
| Package Quantity | SMD | Size / Dimension | 0.60" L x 0.30" W x 0.26" H (15.2mm x 7.6mm x 6.6mm) |
| Number of Positions | 10 | Shell Size - Insert | 6.35(Max) |
Product Info
| Type | Step Down | Series | NTA |
| Printed Circuit Board | 10 | ||
Environmental
| Operating Temperature | -40°C ~ 85°C | Maximum Temperature Limit | +85°C |
