D1U4-W-1600-12-HA2C
| Manufacturer | |
| Description | AC/DC Power Supply Single-OUT 12V 131.6A 1.6KW POWER SUPPLY 1600W AC/DC 12V Switching Power Supplies 1600W 12Vmain 5Vsb back-front airflow |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 1 | Unit Pack | 1 |
| Other Names | 811-1947 | Product Category | Switching Power Supplies |
| Standard Package | Bulk | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Approval Agency | c-CSA-us, CSA, EN, TUV, UL | ||
Electrical
| Frequency | 47 to 63 Hz | Efficiency | 90.6(Typ) % |
| Power - Max | 1600 W | Output Power | 1.2 kW, 1.6 kW |
| Power (Watts) | 1600W | Voltage Rating | 90 to 264 V |
| Current - Output | 131.6 A | Number of Outputs | 1 |
| Power Supply Type | Switching (Closed Frame) | Power (Watts) - Max | 1600W |
| Voltage - Isolation | 3000VAC | Current Rating (Max) | 15(rms) A |
| Voltage - Input (Min) | 12V | Current - Output / Channel | 98.3 A |
Mechanical
| Width | 4 in | Height | 1.6 in |
| Length | 14 in | Packaging | Case |
| Mounting Type | Chassis | Length - Overall | 364.48 |
| Size / Dimension | 14.00" L x 4.00" W x 1.60" H (355.6mm x 101.6mm x 41.0mm) | Shell Size - Insert | 41 |
Product Info
| Type | Regulated | Style | Enclosed |
| Application | Commercial | Applications | Commercial |
Environmental
| Operating Temperature | 0 to 50 °C | ||
