56200C
| Manufacturer | |
| Description | Current Transformer 1:200 500VDC 1.87Ohm/2.81Ohm Prim. DCR 10000mA Through Hole Murata 10A Through Hole Current Transformer, 1:200 Current Transformer Sensors 80-150mH at 1V 10kHz 10A 200 turns CURRENT TRANSFORMER Murata Power Solutions 10A 通孔 电流互感器 CT, 1:200匝数比 |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 25 | Lead Time | 84 Days |
| Unit Pack | 25 | Subcategory | Current Transformer |
| Product Category | Current Transformer Sensors | Standard Package | Bulk |
| Factory Pack Quantity | 25 | ||
Compliance
| RoHS | Compliant | Tariff No | 85043180 |
Electrical
| Frequency | 20 to 200 KHz | Inductance | 80000/150000 uH |
| Frequency - Max | 200kHz | Frequency - Min | :20kHz |
| Current - Output | 10000 mA | Voltage - Primary | 5 V |
| Voltage - Isolation | 500V dc | Current Rating (Max) | 10 A |
| Frequency - Operating | 20kHz | DC Resistance (DCR) (Max) | :2.81ohm |
| Current - Input Bias (Max) | 10A | DC Resistance (DCR) - Primary | 1.87/2.81 Ohm |
| DC Resistance (DCR) - Secondary | :200ohm | Turns Ratio - Primary:Secondary | 1:200 |
Mechanical
| Depth | 20.19mm | Width | 8.89mm |
| Height | 20.19 mm | Length | 16.79mm |
| Weight | 0 | Packaging | Tube |
| Lead Style | PC Pin | Mounting Type | Through Hole |
| Inner Diameter | 5mm | Mounting Style | Through Hole |
| Size / Dimension | 16.79 x 8.89 x 20.19mm | ||
Product Info
| For Use With/Related Products | 56200 | ||
Environmental
| Operating Temperature | -40°C | Maximum Temperature Limit | +85°C |
