BLM03PG330SN1D
| Manufacturer | |
| Description | MONOLITHIC CERMIC CAPACITORS Ferrite Beads Chip 33Ohm 25% 100MHz 750mA 90mOhm DCR 0201 Paper T/R FERRITE CHIP 33 OHMS 750MA 0201 EMI Filter Beads, Chips & Arrays 33 Ohm 25% Murata Power Solutions BLM 系列 铁氧体磁珠, 33Ω阻抗 @ 100 MHZ, 603封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Ferrite Chip Beads | Lead Time | 49 Days |
| Other Names | 490-5175-2 | Subcategory | Ferrite Beads |
| Standard Package | Tape & Reel | Factory Pack Quantity | 15000 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| B25/100 | 33Ω | Impedance | 33 Ohms |
| Tolerance | 25% | Filter Type | Differential Mode - Single |
| Test Frequency | 100 MHz | DC Resistance (DCR) | 90 mOhm Max |
| Current Rating (Max) | 750mA | Impedance @ Frequency | 33 Ohm @ 100MHz |
| Resistance - Initial (Ri) (Min) | 90 mOhms | ||
Mechanical
| Depth | 0.3mm | Width | 0.3 mm |
| Height | 0.3mm | Length | 0.6mm |
| Material | 铁氧体 | Packaging | Paper Tape and Reel |
| Height (Max) | 0.013" (0.33mm) | Mounting Type | Surface Mount |
| Package / Case | 0201 | Length - Overall | 0.63 |
| Size / Dimension | 0.024" L x 0.012" W (0.60mm x 0.30mm) | Termination Style | SMD/SMT |
Product Info
| Type | Chip Bead | Series | BLM |
| Function | Y | Applications | 通用 |
Environmental
| Operating Temperature | - 55 C to + 125 C | ||
