76650-0192
| Manufacturer | |
| Description | Deluxe Board Stacking Solution Kit KIT MULTI STACKING APPLICATIONS Board to Board & Mezzanine Connectors BOARD TO BOARD KIT APPLIANCE Kit Description:Includes KK100, HDM, EBBI 50D, SEARAY, Plateau HS Mezz, IEEE1386, Slimstack Product Families. Pitches range: 0.635mm (.025)" - 2.54mm (0.1)"Kit Category:Board to BoardSolution:Board to Board Packaging:Tackle Box: 11" by 7.25"Num. Pieces:55 DELUXE BOARD STACKING APPLICATION KIT |
| Category |
Business
| Standard Pack | 1 | Part # Aliases | 0766500192 |
| Product Category | Board to Board & Mezzanine Connectors | Standard Package | Bulk |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Voltage | 30, 100, 240 V | Voltage Rating | 30 V, 100 V, 240 V |
| Current Rating (Max) | 500 mA | ||
Mechanical
| Pitch | 0.635 mm, 1 mm, 1.2 mm, 1.27 mm, 2 mm, 2.54 mm | Packaging | Plastic Box with Bin Guide |
| Mounting Type | Vertical | Connector Type | Receptacle, Headers and Plugs |
| Termination Style | SMD | Number of Contacts | 2 to 200 |
Product Info
| Series | 76650 | Values | 55 pcs - Assorted 2 ~ 4, 6, 8, 12, 20, 50, 64, 72 Positions |
| Kit Type | Board to Board - Arrays, Edge Type, Mezzanine, Rectangular - Headers, Receptacles | Manufacturer | 76650 |
| Product Type | Kits | Configuration | Board-to-Board |
| Number of Circuits | 2, 3, 4, 6, 8, 12, 20, 50, 64, 72, 200 | ||
Documents & Media
Similar Parts
44812-0002
Molex Connector Corporation
CONN RECEPT 2POS .100" TIN PCB Molex 2.54mm 2 Way 1 Row Straight PCB Socket Through Hole Socket Strip Headers & Wire Housings 2.54 Recept. 2 CKT Top/bottom Entry Tin Conn Socket Strip RCP 2 POS 2.54mm Solder ST Thru-Hole Tray SOCKET, PCB, 0.1", 2WAY Molex KK 254 系列 2路 直 2.54mm节距 通孔 印刷电路板插座, 插座板
44812-0006
Molex Connector Corporation
CONN RECEPT 6POS .100" TIN PCB Molex 2.54mm 6 Way 1 Row Straight PCB Socket Through Hole Socket Strip Headers & Wire Housings 2.54 Recept. 6 CKT Top/bottom Entry Tin 2.54mm Pitch KK® PC Board Receptacle, Top and Bottom Entry, Low Profile, 5.00µm Tin (Sn), 6 Circuits SOCKET, PCB, 0.1", 6WAY Molex KK 254 系列 6路 直 2.54mm节距 通孔 印刷电路板插座, 插座板
71661-7050
Molex Connector Corporation
CONN PLUG VERTICAL 50POS .050 Board to Board & Mezzanine Connectors 1.27MM VERT 50P PLG BLIND MATE Conn EBBI PL 50 POS 2.54mm Solder ST Thru-Hole 50Terminal 1Port Tray Conn EBBI PL 50 POS 2.54mm Solder ST Thru-Hole 50 Terminal 1 Port Tray
52885-0274
