5025840470
| Manufacturer | |
| Description | Conn Wire to Board RCP 4 POS 1.5mm Solder ST SMD Embossed T/R CONN RCPT 4CKT VERT BEIGE 1.5W/BSglSTRecAssy4CktEmbsTpPkg Socket; wire-board; male; PIN:4; 1.5mm; SMT; Clik-Mate; 2A; tinned |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 502584-0470 | Standard Package | 900 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Voltage - Rated | 100V | Current Rating (Max) | 2A |
| Voltage - Input (Min) | 100V | ||
Mechanical
| Color | Beige | Depth | 6.35 |
| Pitch | 0.059" (1.50mm) | Height | 7.25 |
| Weight | 2.44 g | Packaging | Embossed Tape and Reel |
| Orientation | vertical | Termination | Solder |
| Weight (g): | 6.7 | Contact Form | Center Strip Contact |
| Contact Type | Center Strip Contact | Pitch - Post | 1.5mm |
| Housing Color | Beige | Mounting Type | Surface Mount |
| Connector Type | Receptacle | Contact Finish | Tin Over Nickel |
| Fastening Type | Latch Holder | Number of Rows | 1 |
| Locking Feature | lock | Contact Material | Copper Alloy |
| Housing Material | Resin | Length - Overall | 10.3 |
| Package Quantity | 20 | Connector - Cable | socket |
| Number of Contacts | 4 | Number of Positions | 4 |
| Contact Finish Thickness | 39µin (1.00µm) | Contact Material - Plating | tinned |
| Number of Positions/Bay/Row | All | 1st Connector Mounting Feature | 1x4 |
Product Info
| Spg | 20 | Name | 针座 |
| Type | Wire to Board | Unit | PCS |
| Gender | RCP | Series | CLIK-Mate™ 502584 |
| Features | Solder Retention | Quantity | 5400.0 |
| Main Purpose | Solder Retention | Adapter Series | Clik-Mate |
| Number of Units | 1 | Output Configuration | Surface Mount |
| Manufacturing Country | 日本 | Minimum Order Quantity | 900 |
| Number of Positions Loaded | All | ||
Environmental
| Operating Temperature | -25...85°C | ||
