45985-1422
| Manufacturer | |
| Description | Conn LPH HDR 10Power/16Signal POS 2.5mm/2.54mm Solder RA Thru-Hole 66 Terminal 1 Port Tray 45985 26 Male Right Angle Heavy Duty Power Connector, Through Hole 1, 20A,30, 250V dc, V Heavy Duty Power Connectors LPH Plug Assy RtAn 1 0 Pwr 16 Sig P and G PLUG, R/A, G/POSTS, 10P, 16S |
| Category |
对参数有疑问？问 AI 助手
Business
| Tradename | EXTreme LPHPower | Part # Aliases | 0459851422 |
| Product Category | Heavy Duty Power Connectors | Standard Package | Trays |
| Factory Pack Quantity | 80 | ||
Compliance
| RoHS | Compliant | Tariff No | 85369010 |
Electrical
| Voltage Rating | 250 V, 30 V dc | Current Rating (Max) | 1 A, 20 A |
Mechanical
| Pitch | 2.5/2.54 mm | Weight | 0.05 |
| Packaging | Tray | Termination | Solder |
| Mounting Type | Through Hole | Connector Type | :Backplane |
| Contact Finish | Gold over Nickel | Mounting Style | Right Angle |
| Number of Rows | :2 | Contact Material | Copper Alloy, Phosphor Bronze |
| Housing Material | Thermoplastic | Termination Style | Through Hole |
| Number of Contacts | 10Power/16Signal | Contact Termination | :Through Hole Right Angle |
Product Info
| Type | LPH | Gender | HDR |
| Series | 45985 | ||
