26-60-5030
| Manufacturer | |
| Description | Molex 41792 Series 3.96mm Pitch 3 Way 1 Row Right Angle PCB Header, Solder Termination, 7A Headers & Wire Housings R/A PCB HDR 3P TIN FRICTION LOCK Conn Wire to Board HDR 3 POS 3.96mm Solder RA Thru-Hole Bag HEADER, 3.96MM, R/A, 3WAY Molex KK 396 系列 3.96mm节距 3路 (1排) 直角 PCB 针座, 焊接端接, 7A , 通孔 |
| Category |
对参数有疑问？问 AI 助手
Business
| Tradename | KK | Part # Aliases | 0026605030 41792-0003 |
| Product Category | Headers & Wire Housings | Factory Pack Quantity | 600 |
Compliance
| RoHS | RoHS Compliant | Tariff No | 85369010 |
| Material Flammability Rating | :UL94V-0 | ||
Electrical
| Range deg/s | :MOLEX - KK 41792 Series | Voltage Rating | 250 V |
| Contact Resistance | :6mohm | Voltage - Breakdown | :1500V |
| Current Rating (Max) | 7A | ||
Mechanical
| Pitch | 3.96mm | Weight | 0.001419 |
| Material | :Polyester | Termination | Solder |
| Lead Spacing | :3.96mm | Mounting Type | Right Angle |
| Contact Finish | Tin | Number of Rows | 1 |
| Material Finish | :- | Contact Material | Phosphor Bronze |
| Housing Material | Polyester | Termination Style | Through Hole |
| Color - Connectors | :Natural | Number of Contacts | 3 |
| Contact Termination | :Through Hole Right Angle | ||
Product Info
| Type | Wire to Board | Gender | :Header |
| Series | 41792 | CAD Drawing | 3D CAD Model |
| Product Type | Headers | ||
Environmental
| Mating Cycles | :25 | Operating Temperature | :75°C |
