10-01-3036
| Category |
对参数有疑问？问 AI 助手
Business
| Tradename | SPOX | Part # Aliases | 0010013036 10-01-3036-PB 5197-03 |
| Product Category | Headers & Wire Housings | Standard Package | Bulk |
| Factory Pack Quantity | 1000 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Mechanical
| Color | Natural | Depth | 16mm |
| Pitch | 0.200" (5.08mm) | Width | 8.85mm |
| Length | 15.16mm | Packaging | Bulk |
| Orientation | 直 | Contact Type | Female Socket |
| Mounting Type | Straight | Connector Type | Receptacle |
| Fastening Type | Locking Ramp | Mounting Style | Wire |
| Number of Rows | 1 | Housing Material | Nylon |
| Termination Style | Crimp | 1st Contact Gender | Socket (Female) |
| Number of Contacts | 3 | Contact Termination | Crimp |
| Number of Positions | 3 | ||
Product Info
| Note | Contacts Not Provided | Gender | RCP |
| Series | 5197 | Product Type | Receptacles / Sockets - Housings |
| Base Product Number | 5197 | For Use With/Related Products | SPOX Connector |
Documents & Media
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- 0010013036_CRIMP_HOUSINGS.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
