0681512025
| Manufacturer | |
| Description | Conn Wire to Board HDR 20 POS 2.5mm Solder RA Thru-Hole Tray 040 W/B 20P HEAD ASSY HZT Connector |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Trays | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Current Rating (Max) | 5/Contact | Voltage - Input (Min) | 12V |
Mechanical
| Color | Gray | Depth | 17.7 |
| Pitch | 2.5 mm | Height | 16.9 |
| Packaging | Tray | Row Spacing | 0.205" (5.20mm) |
| Termination | Solder | Contact Type | Male Pin |
| Housing Color | Gray | Mounting Type | Through Hole |
| Connector Type | Header, Shrouded | Contact Finish | Tin |
| Fastening Type | Latch Lock | Number of Rows | 2 |
| Contact Material | Brass | Housing Material | Polyester |
| Length - Overall | 40.1 | Number of Contacts | 20 |
| Number of Positions | 20 | Contact Length - Mating | 0.276" (7.00mm) |
Product Info
| Type | Wire to Board | Gender | HDR |
| Number of Positions Loaded | All | ||
