0541324097
| Manufacturer | |
| Description | Conn FPC Connector SKT 40 POS 0.5mm Solder RA SMD Embossed T/R CONN FFC/FPC .50MM 40POS R/A SMD |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | WM7706CT | Standard Package | Cut Tape |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Voltage Rating | 50V | Contact Resistance | 20 mohm |
| Current Rating (Max) | 0.5A | Voltage - Input (Min) | 50V |
| Voltage - Supply (Min) | 50V | ||
Mechanical
| Depth | 5.6 mm | Pitch | 0.020" (0.50mm) |
| Height | 2 mm | Packaging | Embossed Tape and Reel |
| Termination | Solder | Housing Color | Black |
| Mounting Type | Right Angle | Cable End Type | Straight |
| Connector Type | Bottom Contacts | Contact Finish | Tin Bismuth Over Nickel |
| Mounting Style | Surface Mount | Number of Rows | 1 |
| Locking Feature | Slide Lock | Contact Material | Phosphor Bronze |
| Housing Material | Nylon 46 | Length - Overall | 25.5 mm |
| 1st Contact Gender | SKT | FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.079" (2.00mm) | Number of Contacts | 40 |
| Number of Positions | 40 | Contact Finish Thickness | 39µin (1.00µm) |
Product Info
| Type | FPC Connector | Features | Solder Retention, Zero Insertion Force (ZIF) |
Environmental
| Operating Temperature | -20°C ~ 85°C | ||
