0510470400
| Manufacturer | |
| Description | Conn Housing PL 4 POS 1.25mm Crimp ST Bag Conn Housing M 4 POS 1.25mm Crimp ST Cable Mount Bag 1.25 W/W CONN PLUG HSG 4CKT Conn Housing PL 4 POS 1.25mm ST Bag |
| Category |
Business
| Lead Time | 48 Days | Subcategory | Connector Discrete Wire Housing |
| Standard Package | Bulk | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Current Rating (Max) | 1/Contact A | Voltage - Input (Min) | 125V |
| Voltage - Supply (Min) | 125V | ||
Mechanical
| Color | Natural | Depth | 8 mm |
| Pitch | 1.25 mm | Height | 3.2 mm |
| Packaging | Bag | Contact Type | Male Pin |
| Housing Color | Natural | Mounting Type | Straight |
| Connector Type | Plug | Number of Rows | 1 |
| Housing Material | Polyester | Length - Overall | 6.75 mm |
| Number of Contacts | 4 | Contact Termination | Crimp |
| Number of Positions | 4 | ||
Product Info
| Note | Contacts Not Provided | Type | Housing |
| Gender | PL | Industry Aliases | 51047-0400, 510470400 |
Environmental
| Operating Temperature | -40C to 85C | ||
Documents & Media
Similar Parts
0510210400
Molex, LLC
. 0510210400 - 4 Position Rectangular Housing Connector Receptacle Natural 0.049" (1.25mm) from Molex. from now!
0501338000
Molex, LLC
. 0501338000 - Pin Contact Tin 28-32 AWG Crimp from Molex. from now!
0501258000
molex
Contact PIN Crimp ST Cable Mount Reel CONN TERM MALE 26-28AWG TIN T&R
0510210401
Molex, LLC
. 0510210401 - 4 Position Rectangular Housing Connector Receptacle Black 0.049" (1.25mm) from Molex. from now!
76650-0125
