0448120025

Manufacturer	Molex, LLC
Description	Conn Socket Strip RCP 7 POS 2.54mm Solder ST Thru-Hole Tray CONN RECPT 7POS .100" 15GOLD PCB
Category	Connector SolutionsRectangular ConnectorsHigh-Reliability Rectangular Connectors

对参数有疑问？问 AI 助手

Business

Standard Package

Compliance

RoHS

Lead free / RoHS Compliant

EU RoHS

Compliant

Electrical

Contact Resistance	30	Current Rating (Max)	5/Contact
Voltage - Input (Min)	250V

Mechanical

Color	Black	Depth	7.5
Pitch	0.100" (2.54mm)	Height	4.5
Packaging	Tray	Termination	Solder
Contact Type	Female Socket	Housing Color	Black
Mounting Type	Through Hole	Connector Type	Receptacle, Bottom or Top Entry
Contact Finish	Gold Over Nickel	Number of Rows	1
Contact Material	Brass Alloy	Housing Material	Nylon
Length - Overall	18.54	Number of Contacts	7
Number of Positions	7	Contact Finish Thickness	15µin (0.38µm)

Product Info

Type	Socket Strip	Gender	RCP
Number of Positions Loaded	All

Environmental

Ingress Protection

Operating Temperature

-40°C ~ 105°C
