0436500201
| Manufacturer | |
| Description | Conn Wire to Board HDR 2 POS 3mm Solder RA Thru-Hole Tray Conn Power HDR 2 POS 3mm Solder RA Thru-Hole 2 Terminal 1 Port Tray CONN HEADER 2POS 3MM RT ANG GOLD |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Bulk | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Current Rating (Max) | 5/Contact | Voltage - Input (Min) | 250V |
Mechanical
| Color | Black | Depth | 9.9 |
| Pitch | 3 mm | Height | 5.57 |
| Packaging | Tray | Termination | Solder |
| Contact Type | Male Pin | Mounting Type | Through Hole |
| Connector Type | Header, Shrouded | Contact Finish | Gold Over Nickel |
| Fastening Type | Locking Ramp | Number of Rows | 1 |
| Contact Material | Brass | Housing Material | Liquid Crystal Polymer |
| Length - Overall | 9.65 | Number of Contacts | 2 |
| Number of Positions | 2 | Contact Finish Thickness | 15µin (0.38µm) |
Product Info
| Type | Wire to Board | Gender | HDR |
| Features | Board Lock | Number of Ports | 1 |
| Number of Positions Loaded | All | ||
Environmental
| Operating Temperature | 105 | ||
Documents & Media
PDF Document
