0022012165

Manufacturer	Molex, LLC
Description	Conn Housing RCP 16 POS 2.54mm Crimp ST Cable Mount Bag Conn Housing F 16 POS 2.54mm Crimp ST Cable Mount Bag HSNG RCPT 16POS 2.54MM KK CRIMP
Category	Connector SolutionsRectangular ConnectorsFPC/FFC Rectangular Connectors

对参数有疑问？问 AI 助手

Business

Lead Time	36 Days	Subcategory	Connector Discrete Wire Housing
Standard Package	Bulk

Compliance

RoHS

Lead free / RoHS Compliant

EU RoHS

Compliant

Electrical

Current Rating (Max)	4/Contact A	Voltage - Input (Min)	250V
Voltage - Supply (Min)	250V

Mechanical

Color	Natural	Depth	12.7 mm
Pitch	0.100" (2.54mm)	Height	4.83 mm
Packaging	Bag	Wire Gauge	22-28
Contact Type	Non Gendered	Housing Color	White
Mounting Type	Straight	Connector Type	Receptacle
Number of Rows	1	Housing Material	Polyamide 66/6
Length - Overall	41.1 mm	Number of Contacts	16
Contact Termination	Crimp	Number of Positions	16

Product Info

Note	Contacts Not Provided	Type	Housing
Gender	F	Industry Aliases	22-01-2165, 22012165

Environmental

Operating Temperature

0C to 75C

Documents & Media

PDF Document

Datasheets

Online Document

Product Training Modules

PDF Document

Environmental Information

PDF Document

PCN Obsolescence/ EOL

PDF Document

datasheet
