0008500114

Manufacturer	Molex, LLC
Description	Contact SKT Crimp ST Cable Mount Bag CONN TERM FEMALE 22-30AWG TIN Conn Contact F 1 POS Crimp ST Cable Mount Bag
Category	Connector SolutionsContactsContacts

对参数有疑问？问 AI 助手

Business

Lead Time	20 Days	Subcategory	Connector Contact
Standard Package	Bulk

Compliance

RoHS

Lead free / RoHS Compliant

Electrical

Contact Resistance	20 mohm	Current Rating (Max)	4 A
Voltage - Supply (Min)	250VAC

Mechanical

Depth	2 mm	Pitch	Not Required mm
Height	3.68 mm	Packaging	Bag
Wire Gauge	22-30 AWG	Termination	Crimp
Contact Type	Signal	Housing Color	Not Required
Mounting Type	Straight	Pin or Socket	Non-Gendered
Connector Type	Connector Headers and PCB Receptacles	Contact Finish	Tin Over Nickel
Mounting Style	Cable	Contact Material	Brass
Housing Material	Not Required	Length - Overall	9.7 mm
Number of Contacts	Not Required	Contact Termination	Crimp
Contact Finish Thickness	100µin (2.54µm)

Product Info

Type	Contact	Gender	SKT
Industry Aliases	08-50-0114, 08500114, 8500114	For Use With/Related Products	0008500113

Documents & Media

PDF Document

0008500114_CRIMP_TERMINALS.pdf
