FX1S-30MR-DS
| Manufacturer | |
| Description | Mitsubishi PLC CPU FX1S, Program Capacity 2000Steps 30 I/O Ports DIN Rail 2A Mitsubishi FX1S系列 PLC CPU, 2000 步编程容量, 30 I/O 端口, DIN导轨安装, 24 V 直流类别 |
| Category |
对参数有疑问？问 AI 助手
Electrical
| Fall Time | 0.55 → 0.7 μs | Interface | Computer |
| Input Type | Digital | EEPROM Size | 2000 步 |
| Output Type | Relay | Number of I/O | 30 |
| Response Time | 0.55 → 0.7 μs | Voltage Rating | 24 V dc |
| Current - Output | 2 A | Number of Inputs | 16 (Digital) |
| Number of Outputs | 14 (Relay) | Program Memory Size | 2000 Steps |
| Current Rating (Max) | 2 A | ||
Mechanical
| Depth | 49mm | Width | 100mm |
| Length | 90mm | Contact Type | RS422 |
| Mounting Type | DIN Rail | Connector Type | RS422 |
| Size / Dimension | 90 x 100 x 49 mm | ||
Product Info
| Series | FX1S | Language | 梯形逻辑 |
| Programmable | Ladder Logic | Adapter Series | FX1S Series |
| Number of Ports | 1 | Number of Inputs and Type | 30 |
| For Use With/Related Products | FX1S Series | ||
Environmental
| Operating Temperature | +55°C | ||
