896-43-008-90-000000
| Manufacturer | |
| Description | USB Connectors TYPE A DOUBLE Conn USB Type A SKT 8 POS Solder RA Thru-Hole 8 Terminal 2 Port Tube CONN RECEPT USB DBL TYPE A PCB USB TYPE A CONNECTOR RECEPTACLE 8POS THD USBRecepDoubleThru-holeAType |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | USB Type A Connectors | Product Category | USB Connectors |
| Standard Package | 120 | Factory Pack Quantity | 120 |
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85369010 | ||
Electrical
| Voltage - Supply | USB | Current Rating (Max) | 1/Contact |
| Insulation Resistance | 1000 MOhms | Voltage - Input (Min) | 150VDC|100VAC |
Mechanical
| Depth | 16.96 | Weight | 0.005 |
| Packaging | Tube | Termination | Solder |
| Mounting Type | Right | Connector Type | USB Type A Receptacle |
| Contact Finish | Gold | Mounting Style | SMD/SMT |
| Contact Material | Copper Alloy | Housing Material | Polybutylene Terephthalate |
| Length - Overall | 14.5 | Number of Contacts | 4 |
| Contact Termination | :Through Hole Right Angle | 1st Connector Mounting Type | :PCB |
Product Info
| Type | USB Type A | Gender | Female |
| Series | :896 | Specifications | USB 2.0 |
| Number of Ports | 1 | ||
Documents & Media
PDF Document
