896-43-004-90-000000
| Manufacturer | |
| Description | USB Connectors TYPE A SINGLE Conn USB Type A RCP 4 POS Solder RA Thru-Hole 4 Terminal 1 Port Tray CONN RECEPT USB TYPE A PCB Conn USB Type A RCP 4 POS Solder RA Thru-Hole 4 Terminal 1 Port Tube USB TYPE A CONNECTOR RECEPTACLE 4POS THD USBRecepSingleThru-holeAType |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | USB Type A Connectors | Product Category | USB Connectors |
| Standard Package | 150 | Factory Pack Quantity | 150 |
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85369010 | ||
Electrical
| Voltage - Supply | USB | Current Rating (Max) | 1 A |
| Insulation Resistance | 1000 MOhms | Voltage - Input (Min) | 150VDC|100VAC |
| Voltage - Supply (Min) | 30VAC | ||
Mechanical
| Depth | 13.99 mm | Height | 7.11 mm |
| Weight | 0.002 | Diameter | Not Required mm |
| Packaging | Tube | Termination | Solder |
| Mounting Type | Right | Connector Type | USB Type A Receptacle |
| Contact Finish | Gold | Mounting Style | SMD/SMT |
| Contact Material | Copper Alloy | Housing Material | Polybutylene Terephthalate |
| Number of Contacts | 4 | Contact Termination | :Through Hole Right Angle |
| 1st Connector Mounting Type | :PCB | ||
Product Info
| Type | USB Type A | Gender | Female |
| Series | :896 | DELETED | Compliant |
| Specifications | USB 2.0 | Number of Ports | 1 |
