896-43-004-00-000000
| Manufacturer | |
| Description | USB Connectors TYPE A SINGLE SMT Conn USB Type A RCP 4 POS Solder RA SMD 4 Terminal 1 Port Tube CONN RECEPT USB TYPE A SMT USB TYPE A CONNECTOR RECEPTACLE 4POS SMD USBRecepSingleSMTAType |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | USB Type A Connectors | Product Category | USB Connectors |
| Standard Package | 150 | Factory Pack Quantity | 150 |
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85369010 | ||
Electrical
| Voltage - Supply | USB | Current Rating (Max) | 1 A |
| Insulation Resistance | 1000 MOhms | Voltage - Input (Min) | 150VDC|100VAC |
| Voltage - Supply (Min) | 30VAC | ||
Mechanical
| Depth | 13.99 mm | Height | 7.11 mm |
| Weight | 0.002 | Packaging | Tube |
| Termination | Solder | Mounting Type | Right |
| Connector Type | USB Type A Receptacle | Contact Finish | Gold |
| Mounting Style | SMD/SMT | Contact Material | Copper Alloy |
| Housing Material | Polybutylene Terephthalate | Number of Contacts | 4 |
| Contact Termination | :Surface Mount Right Angle | 1st Connector Mounting Type | :PCB |
Product Info
| Type | USB Type A | Gender | Female |
| Series | :896 | DELETED | Compliant |
| Specifications | USB 2.0 | Number of Ports | 1 |
Documents & Media
PDF Document
