8579-0-15-15-11-27-10-0
| Manufacturer | |
| Description | Circuit Board Hardware - PCB Receptacle No Tail .015-.022 Contact SKT Solder ST Thru-Hole Bulk CONN PIN RECEPT .015-.020" PIN RECEPTACLE, PC BOARD, SOLDER |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Receptacles | Product Category | Circuit Board Hardware - PCB |
| Standard Package | 500 | ||
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85366910 | ||
Electrical
| Contact Resistance | 10 | Current Rating (Max) | 3 A |
Mechanical
| Depth | 1.39 | Height | 1.39 |
| Length | 5.94 mm | Weight | 0.002 |
| Plating | Gold over Nickel | Material | Beryllium Copper Alloy |
| Packaging | Bulk | Tail Type | No Tail |
| Shield Type | No | Termination | Solder |
| Contact Size | 11 | Socket Depth | 0.195" (4.95mm) |
| Mounting Type | Through Hole | Connector Type | Connector Socket |
| Contact Finish | Gold Over Nickel | Flange Diameter | 0.055" (1.40mm) |
| Contact Material | Beryllium Copper Alloy | Length - Overall | 0.234" (5.94mm) |
| Pin Hole Diameter | 0.031" (0.79mm) | Diameter - Outside | 1.4 mm |
| Number of Contacts | :1 | Contact Termination | :Solder |
| Accepts Pin Diameter | 0.015" ~ 0.020" (0.38mm ~ 0.51mm) | Mounting Hole Diameter | 0.040" (1.02mm) |
| Contact Finish Thickness | 30µin (0.76µm) | 1st Connector Mounting Type | :PCB |
Product Info
| Type | Pin Receptacles | Gender | SKT |
| Series | :8579 | ||
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
