813-22-072-30-003101
| Manufacturer | |
| Description | Conn Unshrouded Header HDR 72 POS 2.54mm Solder ST SMD Bulk CONN SPRING CONT 72 POS .217 SMD Headers & Wire Housings 72P DOUBLE ROW HDR PIN HEIGHT .217 |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Headers & Wire Housings | Standard Package | 5 |
| Factory Pack Quantity | 5 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Contact Resistance | 20 | Current Rating (Max) | 3 A |
| Voltage - Input (Min) | 150VDC|100VAC | ||
Mechanical
| Depth | 5.08 | Pitch | 0.100" (2.54mm) |
| Height | 5.51 | Material | Copper Alloy |
| Packaging | Bulk | Row Spacing | 0.100" (2.54mm) |
| Termination | Solder | Housing Color | Black |
| Mounting Type | Surface Mount | Connector Type | Piston |
| Contact Finish | Gold Over Nickel | Number of Rows | 2 |
| Contact Material | Brass Alloy | Housing Material | Nylon 46 |
| Length - Overall | 91.44 | Number of Contacts | 72 |
| Contact Finish Thickness | 20µin (0.51µm) | ||
Product Info
| Type | Unshrouded Header | Gender | HDR |
| Series | 813 | Product Type | Contacts |
