3157-0-00-15-00-00-03-0
| Manufacturer | |
| Description | Circuit Board Hardware - PCB Solderless PCB Pin Pressfit .125 Contact PIN Press Fit ST Bulk CONN PC PIN CIRC .023DIA GOLD TEST POINT PIN, PCB, PRESS FIT |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Pins | Product Category | Circuit Board Hardware - PCB |
| Standard Package | 500 | ||
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85369010 | ||
Mechanical
| Depth | 1.14 mm | Pitch | Not Required mm |
| Length | 4.83 mm | Weight | 0.002 |
| Material | Brass Alloy | Packaging | Bulk |
| Tip Shape | :Radius | Insulation | Non-Insulated |
| Termination | Press Fit | Contact Type | Signal |
| Housing Color | Not Required | Length - Tail | 0.125" (3.18mm) |
| Mounting Type | Straight | Terminal Type | Single End |
| Connector Type | Connector Headers and PCB Recepta... | Contact Finish | Gold Over Nickel |
| Mounting Style | Press Fit | Flange Diameter | 0.045" (1.14mm) |
| Contact Material | Brass Alloy | Housing Material | Not Required |
| Length - Overall | 0.190" (4.83mm) | Diameter - Outside | 1.14 mm |
| Number of Contacts | Not Required | Contact Termination | :Press Fit Vertical |
| Mounting Hole Diameter | 0.026" (0.66mm) | Pin Size - Above Flange | 0.023" (0.58mm) Dia |
| Pin Size - Below Flange | 0.018" (0.46mm) Dia | Contact Finish Thickness | 10µin (0.25µm) |
| 1st Connector Mounting Type | :PCB | ||
Product Info
| Type | PCB Pins | Gender | PIN |
| Series | :3157 | ||
