7508110102
| Manufacturer | |
| Description | Transformers Audio & Signal MID-UNIT Transformer 2.58mH 10kHz .118ohm TRANS OFF LINE POWER PI LNK613 |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Transformers | Other Names | 732-2246 |
| Standard Package | 250 | ||
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Frequency | 65kHz | Inductance | 2.58 mH |
| Power - Rated | 2.8 W | Frequency Range | 65 kHz |
| Voltage - Primary | 120 ~ 375V | Voltage - Isolation | 4000Vrms |
| Current Rating (Max) | 330 mA | DC Resistance (DCR) - Secondary | 0.015 Ohms |
| Resistance - Initial (Ri) (Min) | 3.05 Ohms | ||
Mechanical
| Width | 20.32 mm | Height | 16 mm |
| Length | 24.38 mm | Packaging | Tray |
| Mounting Type | Through Hole | Package / Case | 24.38 mm x 20.32 mm x 16 mm |
| Primary Material | 3.05 Ohms | Size / Dimension | 24.38mm L x 20.32mm W |
| Termination Style | Through Hole | Height - Seated (Max) | 16.00mm |
Product Info
| Type | For AC/DC Converters | Series | MID-UNIT |
| Applications | Flyback Converters | Product Type | Offline Transformers |
| Intended Chipset | LNK613 | Chipset Manufacturer | Power Integrations |
Environmental
| Operating Temperature | -40°C ~ 125°C | ||
