PIC24HJ64GP502-I/SO
| Manufacturer | |
| Description | MCU 16-bit PIC24 PIC RISC 64KB Flash 3.3V 28-Pin SOIC W Tube 16-bit MCU, 64KB Flash,CAN,DMA,40 MI IC MCU 16BIT 64KB FLASH 28SOIC PIC24HJ64GP502-I/SO, 16 bit Microcontroller PIC 40MIPS 64kb Flash, 8kb RAM, I2C SPI 28-Pin SOIC 16-bit Microcontrollers - MCU 16B MCU 28LD64KB DMA 40MIPS MCU, 16BIT, 64K FLASH, 40MIPS, 28SOIC IC,PIC24HJ64GP502-I/SO Microchip PIC24HJ 系列 16 bit PIC MCU, 40MIPS, 64 kB ROM 闪存, 8 kB RAM, 28针 SOIC封装 PIC24HJ 64K QFN28 85°C |
| Category |
Business
| MOQ | 150 | Unit Pack | 27 |
| Other Names | PIC24HJ64GP502ISO | Product Category | 16-bit Microcontrollers - MCU |
| Standard Package | Rail / Tube | Factory Pack Quantity | 27 |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85423190 | ||
Electrical
| Speed | 40 MHz | Timer | 5 x 16 bit |
| RAM Size | 8 KB | Core Size | 16-Bit |
| Core Type | PIC | Interface | CAN/I2C/SPI/UART |
| Clock Rate | 40 MHz | Resolution | 16bit |
| Memory Size | 8 KB | Memory Type | :Flash |
| Number of I/O | 21 | Number of Bits | :16 |
| Voltage Rating | 3 → 3.6 V | Watchdog Timer | 1 |
| Clock Frequency | :80MHz | Data Converters | A/D 10x10b/12b |
| FPGA Core Cells | :40 | Frequency - Max | 40MIPS |
| Number of DAC's | 4 | Oscillator Type | Internal |
| Voltage - Supply | 3.3 V | Resolution (Bits) | 10 bit, 12 bit |
| Number of Channels | 1 | Program Memory Size | 64 KB |
| Program Memory Type | Flash | Number of ADCs / DACs | 10 |
| Frequency (Center/Band) | 16bit | Number of Bits per Element | 10 bit, 12 bit |
| Voltage - Supply (Vcc/Vdd) | 3 V ~ 3.6 V | ||
Mechanical
| Width | 7.5mm | Height | 2.35mm |
| Length | 17.9mm | Weight | 0.002963 |
| Packaging | Tube | Termination | :SMD |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :28 | Package / Case | 28SOIC W |
| Package Cooled | SOIC | Material Finish | :MSL 1 - Unlimited |
| Size / Dimension | 17.9 x 7.5 x 2.35mm | Number of Positions | 28 |
| Supplier Device Package | 28-SOIC | Number of Cores/Bus Width | 16 Bit |
| Pulse Width Distortion (Max) | 4(16 bit) | ||
Product Info
| USB | 0 | Series | PIC24H |
| Features | CAN Controller | Flash Size | :64KB |
| On-Chip RAM | 10-chx10-bit|10-chx12-bit | Peripherals | Brown-out Detect/Reset, DMA, POR, PWM, WDT |
| Architecture | RISC | Connectivity | CAN, I²C, IrDA, LIN, PMP, SPI, UART/USART |
| Core Processor | PIC | Number of Timers | 5 |
| Controller Series | :PIC24HJxxGPxxx | RF Family/Standard | PIC24 |
| Number of A/D Converters | :10 | ||
Environmental
| Operating Temperature | -40 to 85 °C | ||
