PIC18F2331-E/SP
| Manufacturer | |
| Description | MCU 8-bit PIC18 PIC RISC 8KB Flash 5V 28-Pin SPDIP Tube 8 KB Flash, 768 RAM, 22 I/O IC MCU 8BIT 8KB FLASH 28SDIP 8-bit Microcontrollers - MCU 8KB 768 RAM 22 I/O |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 183 | Product | MCU |
| Tradename | PIC | Unit Pack | 15 |
| Product Category | 8-bit Microcontrollers - MCU | Standard Package | Rail / Tube |
| Factory Pack Quantity | 15 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Speed | 40 MHz | RAM Size | 768 byte |
| Core Size | 8-Bit | Core Type | PIC |
| Interface | I2C/SPI/USART | Clock Rate | 40 MHz |
| EEPROM Size | 256 x 8 | Memory Size | 768 B |
| Number of I/O | 24 | Watchdog Timer | 1 |
| Data Converters | A/D 5x10b | Oscillator Type | Internal |
| Voltage - Supply | 5 V | Resolution (Bits) | 10 bit |
| Number of Channels | 5 | Program Memory Size | 8 KB |
| Program Memory Type | Flash | Number of ADCs / DACs | 5 |
| Power Dissipation (Max) | 1000 mW | Number of Counter/Timers | 1 Timer |
| Number of Bits per Element | 10 bit | Voltage - Supply (Vcc/Vdd) | 4.2 V ~ 5.5 V |
Mechanical
| Height | 3.3 mm | Length | 34.67 mm |
| Packaging | Tube | Mounting Style | Through Hole |
| Package / Case | 28SPDIP | Supplier Device Package | 28-SPDIP |
| Number of Cores/Bus Width | 8 Bit | ||
Product Info
| Series | PIC18 | On-Chip RAM | 5-chx10-bit |
| Peripherals | Brown-out Detect/Reset, LVD, Power Control PWM, QEI, POR, PWM, WDT | Connectivity | I²C, SPI, UART/USART |
| Manufacturer | Microchip Technology | Core Processor | PIC |
| Number of Timers | 4 | RF Family/Standard | PIC18 |
| Number of Inputs and Type | 24 I/O | ||
Environmental
| Operating Temperature | -40 to 125 °C | ||
