PIC18C252-I/SP
| Manufacturer | |
| Description | MCU 8-bit PIC18 PIC RISC 32KB EPROM 5V 28-Pin SPDIP Tube IC MCU 8BIT 32KB OTP 28SDIP 8-bit Microcontrollers - MCU 32KB 1536 RAM 23I/O IC, 8BIT CMOS MCU, 18C252, SDIL28 28-Pin,32KBOTP,1536RAM,23I/O |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | PIC18C252ISP | Product Category | 8-bit Microcontrollers - MCU |
| Standard Package | Rail / Tube | Factory Pack Quantity | 15 |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85423190 | Part Status | :18C252 |
| Rad Hardened | No | ||
Electrical
| Input | 23 | Speed | 40 MHz |
| Timer | 1-8-bit,3-16-bit | Memory | :32KB |
| RAM Size | 1.5 KB | Core Size | 8-Bit |
| Core Type | PIC | Frequency | 40 MHz |
| Interface | I2C/SPI/USART | Clock Rate | 40 MHz |
| Comparator | 0 | Memory Size | 1536 B |
| Memory Type | :RAM | Number of I/O | 23 |
| Voltage Range | 2.5-5.5V | Number of Bits | :8 |
| Watchdog Timer | 1 | Clock Frequency | :40MHz |
| Data Converters | A/D 5x10b | Number of DAC's | :2 |
| Oscillator Type | External | Voltage - Supply | 5 V |
| Number of Channels | 5 | Analog Input:Output | 5-Channel,10-Bit |
| Non-Volatile Memory | 0Bytes | Program Memory Size | 32 KB |
| Program Memory Type | EPROM | Voltage - Supply (Min) | 4.2 V |
| Power Dissipation (Max) | 1000 mW | Number of Bits per Element | 10 bit |
| Voltage - Supply (Vcc/Vdd) | 4.2 V ~ 5.5 V | ||
Mechanical
| Weight | 0.000001 | Packaging | Tube |
| Mounting Type | Through Hole | Mounting Style | Through Hole |
| Number of Pins | :28 | Package / Case | 28SPDIP |
| Package Cooled | SPDIP | Material Finish | :- |
| Number of Positions | 28 | Supplier Device Package | 28-SPDIP |
| Number of Cores/Bus Width | 8 Bit | ||
Product Info
| Series | PIC18 | On-Chip RAM | 5-chx10-bit |
| Peripherals | Brown-out Detect/Reset, LVD, POR, PWM, WDT | Architecture | RISC |
| Connectivity | I²C, SPI, UART/USART | Programmable | Yes |
| Core Processor | PIC | Number of Timers | 4 |
| Controller Series | :PIC18Cxx2 | RF Family/Standard | PIC18 |
| Microcontroller Features | :8 Kbytes OTP PROM | Number of A/D Converters | :5 |
Environmental
| Temperature Range | :Industrial | Operating Temperature | -40 to 85 °C |
| Operating Temperature - Junction | 85C | ||
