PIC16F883-I/ML
| Manufacturer | |
| Description | MCU 8-bit PIC16 PIC RISC 7KB Flash 2.5V/3.3V/5V 28-Pin QFN EP Tube 8 bit MCU QFN28 IC MCU 8BIT 7KB FLASH 28QFN PIC16F883-I/ML, 8 bit Microcontroller PIC 20MHz 4096 Flash, 256B RAM, I2C SPI 28-Pin QFN 8-bit Microcontrollers - MCU 7KB Flash 256 RAM 25 I/O MCU, 8BIT, PIC16F, 20MHZ, QFN-28 28-Pin,7KBFlash,256RAM,25I/O,QFN PIC16F 7K QFN28 85°C |
| Category |
Business
| MOQ | 61 | Unit Pack | 61 |
| Other Names | PIC16F883IML | Product Category | 8-bit Microcontrollers - MCU |
| Standard Package | Rail / Tube | Factory Pack Quantity | 61 |
| Standard Package Name | QFN | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
| Leadfree Defin | RoHS-conform | Approval Agency | No |
Electrical
| Input | 24 | Speed | 20 MHz |
| Timer | 1 x 16 bit, 2 x 8 bit | Memory | 7KBytes |
| RAM Size | 256 byte | Core Size | 8-Bit |
| Core Type | PIC | Frequency | 20MHz |
| Interface | I2C/SPI/USART | Clock Rate | 20 MHz |
| Comparator | 2 | Resolution | 10bit |
| EEPROM Size | 256Byte | Memory Size | 7KByte |
| Memory Type | Flash | Display Type | 0 |
| Number of I/O | 24 | Voltage Range | 2-5.5V |
| Number of Bits | 10 | Voltage Rating | 2 → 5.5 V |
| Watchdog Timer | 1 | Clock Frequency | :20MHz |
| Data Converters | A/D 11x10b | Frequency - Max | 20MHz |
| Number of DAC's | 2 | Oscillator Type | Internal |
| Voltage - Supply | 2.5|3.3|5 V | Digital I/O Lines | 25pins |
| Resolution (Bits) | 16bit | Serial Interfaces | 1 |
| Number of Channels | 1 | Analog Input:Output | 2 |
| Non-Volatile Memory | 256Bytes | Program Memory Size | 7 KB |
| Program Memory Type | Flash | Number of ADCs / DACs | 11 |
| Voltage - Input (Min) | 3.3V | Voltage - Supply (Min) | 5.5 |
| Frequency (Center/Band) | 16 bit, 8 bit | Power Dissipation (Max) | 800 mW |
| Number of Bits per Element | 10 bit | Voltage - Supply (Vcc/Vdd) | 2 V ~ 5.5 V |
Mechanical
| Width | 6mm | Height | 0.95mm |
| Length | 6mm | Weight | 0.0001 |
| Packaging | TUBE | Lead Style | No Lead |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :28 | Package / Case | 28QFN EP |
| Package Cooled | QFN | Material Finish | :MSL 1 - Unlimited |
| Length - Overall | 6 | Package Quantity | QFN EP |
| Size / Dimension | 6 x 6 x 0.95mm | Number of Positions | 28 |
| Shell Size - Insert | 0.88 | Supplier Device Package | 28-QFN (6x6) |
| Number of Cores/Bus Width | 8 Bit | Pulse Width Distortion (Max) | 1(10 bit) (CCP), 1(10 bit) (ECCP) |
Product Info
| SPI | 1 | USB | No |
| Series | PIC16 | Protocol | 1 |
| Matchcode | PIC16F883-I/ML | CAN Number | 0 |
| SPI Number | 1 | On-Chip RAM | 11-chx10-bit |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT | Architecture | RISC |
| Connectivity | I²C, SPI, UART/USART | Core Processor | PIC |
| Number of Timers | 3 | Controller Series | :PIC16F8xxx |
| Standard Leadtime | 14 weeks | RF Family/Standard | PIC16 |
| DigiKey Programmable | Yes | Printed Circuit Board | 28 |
Environmental
| Operating Temperature | -40 to 85 °C | ||
