PIC16C773-I/SP
| Manufacturer | |
| Description | MCU 8-bit PIC16 PIC RISC 7KB EPROM 5V 28-Pin SPDIP Tube 8-bit Microcontrollers - MCU 7KB 256 RAM 22 I/O 8 bit MCU SPDIP28 IC MCU 8BIT 7KB OTP 28SDIP IC, 8BIT CMOS MCU, 16C773, SDIL28 Microcontroller 8 Bit DIL-28, PIC16C773-I/SP, Microchip |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 135 | Unit Pack | 15 |
| Product Category | 8-bit Microcontrollers - MCU | Standard Package | Rail / Tube |
| Factory Pack Quantity | 15 | ||
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85423190 | Automotive | NO |
| Part Status | :16C773 | Leadfree Defin | RoHS-conform |
Electrical
| Speed | 20 MHz | Memory | :56KB |
| RAM Size | 256 byte | Core Size | 8-Bit |
| Core Type | PIC | Interface | I2C/SPI/USART |
| Clock Rate | 20 MHz | Memory Size | 256 B |
| Memory Type | OTP | Number of I/O | 22 |
| Number of Bits | :8 | Watchdog Timer | 1 |
| Clock Frequency | :20MHz | Data Converters | A/D 6x12b |
| Number of DAC's | :2 | Oscillator Type | External |
| Voltage - Supply | 5 V | Number of Channels | 6 |
| Program Memory Size | 7 KB | Program Memory Type | EPROM |
| Power Dissipation (Max) | 1000 mW | Number of Bits per Element | 12 bit |
| Voltage - Supply (Vcc/Vdd) | 4 V ~ 5.5 V | ||
Mechanical
| Weight | 0.00644 | Packaging | Tube |
| Mounting Style | Through Hole | Number of Pins | :28 |
| Package / Case | 28SPDIP | Material Finish | :- |
| Number of Positions | :16C773 | Supplier Device Package | 28-SPDIP |
| Number of Cores/Bus Width | 8 Bit | ||
Product Info
| Series | PIC16 | Matchcode | PIC16C773-I/SP |
| On-Chip RAM | 6-chx12-bit | Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| Connectivity | I²C, SPI, UART/USART | Core Processor | PIC |
| Number of Timers | 3 | Controller Series | :PIC16C |
| Standard Leadtime | 14 weeks | RF Family/Standard | PIC16 |
| Microcontroller Features | :USART, I2C, SPI, PWM, Brown-Out Protection, Watchdog, In-System programming, Capture/Compare | Number of A/D Converters | :6 |
Environmental
| Temperature Range | :Industrial | Temperature - Test | 0°C |
| Operating Temperature | -40 to 85 °C | ||
