PIC16C771/SO
| Manufacturer | |
| Description | MCU 8-bit PIC16 PIC RISC 7KB EPROM 5V 20-Pin SOIC W Tube 7 KB OTP, 256 RAM, 16 I/O IC MCU 8BIT 7KB OTP 20SOIC 8-bit Microcontrollers - MCU 7KB 256 RAM 16 I/O |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 268 | Product | MCU |
| Tradename | PIC | Unit Pack | 38 |
| Product Category | 8-bit Microcontrollers - MCU | Standard Package | Rail / Tube |
| Factory Pack Quantity | 38 | Standard Package Name | SOIC W |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Approval Agency | No | ||
Electrical
| Speed | 20 MHz | RAM Size | 256 byte |
| Core Size | 8-Bit | Core Type | PIC |
| Interface | I2C/SPI | Clock Rate | 20 MHz |
| Memory Size | 256 B | Number of I/O | 16 |
| Number of Bits | 12 | Voltage Rating | 4 |
| Watchdog Timer | 1 | Data Converters | A/D 6x12b |
| Oscillator Type | Internal | Voltage - Supply | 5 V |
| Resolution (Bits) | 12 bit | Number of Channels | 6 |
| Program Memory Size | 7 KB | Program Memory Type | EPROM |
| Number of ADCs / DACs | 6 | Voltage - Supply (Min) | 5.5 |
| Power Dissipation (Max) | 1000 mW | Number of Counter/Timers | 3 Timer |
| Number of Bits per Element | 12 bit | Voltage - Supply (Vcc/Vdd) | 4 V ~ 5.5 V |
Mechanical
| Width | 7.49 mm | Height | 2.31 mm |
| Length | 12.8 mm | Packaging | Tube |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 20SOIC W |
| Length - Overall | 12.8 | Package Quantity | SOIC W |
| Number of Positions | 20 | Shell Size - Insert | 2.31 |
| Supplier Device Package | 20-SOIC | Number of Cores/Bus Width | 8 Bit |
Product Info
| SPI | 1 | Series | PIC16 |
| Protocol | 1 | On-Chip RAM | 6-chx12-bit |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT | Architecture | RISC |
| Connectivity | I²C, SPI | Manufacturer | Microchip Technology |
| Core Processor | PIC | Number of Timers | 3 |
| RF Family/Standard | PIC16 | DigiKey Programmable | Yes |
| Printed Circuit Board | 20 | Number of Inputs and Type | 16 I/O |
Environmental
| Operating Temperature | 0 to 70 °C | ||
