PIC16C770T-I/SS
| Manufacturer | |
| Description | MCU 8-bit PIC16 PIC RISC 3.5KB EPROM 5V 20-Pin SSOP T/R 3.5 KB OTP, 256 RAM, 16 I/O IC MCU 8BIT 3.5KB OTP 20SSOP 8-bit Microcontrollers - MCU 3.5KB 256 RAM 16 I/O |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 1600 | Product | MCU |
| Tradename | PIC | Unit Pack | 1600 |
| Other Names | PIC16C770TI/SS | Product Category | 8-bit Microcontrollers - MCU |
| Standard Package | Tape & Reel | Factory Pack Quantity | 1600 |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Speed | 20 MHz | RAM Size | 256 byte |
| Core Size | 8-Bit | Core Type | PIC |
| Interface | I2C/SPI | Clock Rate | 20 MHz |
| Memory Size | 256 B | Number of I/O | 16 |
| Watchdog Timer | 1 | Data Converters | A/D 6x12b |
| Oscillator Type | Internal | Voltage - Supply | 5 V |
| Resolution (Bits) | 12 bit | Number of Channels | 6 |
| Program Memory Size | 3.5 KB | Program Memory Type | EPROM |
| Number of ADCs / DACs | 6 | Power Dissipation (Max) | 1000 mW |
| Number of Counter/Timers | 3 Timer | Number of Bits per Element | 12 bit |
| Voltage - Supply (Vcc/Vdd) | 4 V ~ 5.5 V | ||
Mechanical
| Width | 5.3 mm | Height | 1.75 mm |
| Length | 7.2 mm | Packaging | Tape & Reel (TR) |
| Mounting Style | SMD/SMT | Package / Case | 20SSOP |
| Supplier Device Package | 20-SSOP | Number of Cores/Bus Width | 8 Bit |
Product Info
| Series | PIC16 | On-Chip RAM | 6-chx12-bit |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT | Connectivity | I²C, SPI |
| Manufacturer | Microchip Technology | Core Processor | PIC |
| Number of Timers | 3 | RF Family/Standard | PIC16 |
| Number of Inputs and Type | 16 I/O | ||
Environmental
| Operating Temperature | -40 to 85 °C | ||
Documents & Media
PDF Document
