PIC16C716-04I/P
| Manufacturer | |
| Description | MCU 8-bit PIC16 PIC RISC 3.5KB EPROM 5V 18-Pin PDIP Tube 3.5 KB OTP, 128 RAM, 13 I/O IC MCU 8BIT 3.5KB OTP 18DIP 8-bit Microcontrollers - MCU 3.5KB 128 RAM 13 I/O |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 252 | Product | MCU |
| Tradename | PIC | Unit Pack | 25 |
| Other Names | PIC16C71604IP | Product Category | 8-bit Microcontrollers - MCU |
| Standard Package | Rail / Tube | Factory Pack Quantity | 25 |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Speed | 4 MHz | RAM Size | 128 byte |
| Core Size | 8-Bit | Core Type | PIC |
| Clock Rate | 20 MHz | Memory Size | 128 B |
| Number of I/O | 13 | Watchdog Timer | 1 |
| Data Converters | A/D 4x8b | Oscillator Type | External |
| Voltage - Supply | 5 V | Resolution (Bits) | 8 bit |
| Number of Channels | 4 | Program Memory Size | 3.5 KB |
| Program Memory Type | EPROM | Number of ADCs / DACs | 4 |
| Power Dissipation (Max) | 1000 mW | Number of Counter/Timers | 3 Timer |
| Number of Bits per Element | 8 bit | Voltage - Supply (Vcc/Vdd) | 4 V ~ 5.5 V |
Mechanical
| Width | 6.35 mm | Height | 3.3 mm |
| Length | 22.86 mm | Packaging | Tube |
| Mounting Style | Through Hole | Package / Case | 18PDIP |
| Supplier Device Package | 18-PDIP | Number of Cores/Bus Width | 8 Bit |
Product Info
| Series | PIC16 | On-Chip RAM | 4-chx8-bit |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT | Manufacturer | Microchip Technology |
| Core Processor | PIC | Number of Timers | 3 |
| RF Family/Standard | PIC16 | Number of Inputs and Type | 13 I/O |
Environmental
| Operating Temperature | -40 to 85 °C | ||
