PIC12LC508A-04I/P
| Manufacturer | |
| Description | MCU 8-bit PIC12 PIC RISC 768byte EPROM 3.3V/5V 8-Pin PDIP Tube 0.75 KB OTP, 25 RAM, 6 I/O IC MCU 8BIT 768B OTP 8DIP 8-bit Microcontrollers - MCU .75KB 25 RAM 6 I/O 4 MHz IndTemp PDIP8 |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 540 | Product | MCU |
| Tradename | PIC | Unit Pack | 60 |
| Product Category | 8-bit Microcontrollers - MCU | Standard Package | Rail / Tube |
| Factory Pack Quantity | 60 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Speed | 4 MHz | RAM Size | 25 byte |
| Core Size | 8-Bit | Core Type | PIC |
| Clock Rate | 4 MHz | Memory Size | 25 B |
| Number of I/O | 5 | Watchdog Timer | 1 |
| Data Converters | EEPROM | Oscillator Type | Internal |
| Voltage - Supply | 3.3|5 V | Resolution (Bits) | No ADC |
| Program Memory Size | 768 byte | Program Memory Type | EPROM |
| Power Dissipation (Max) | 700 mW | Number of Counter/Timers | 8 Timer |
| Voltage - Supply (Vcc/Vdd) | 2.5 V ~ 5.5 V | ||
Mechanical
| Width | 6.35 mm | Height | 3.3 mm |
| Length | 9.27 mm | Packaging | Tube |
| Mounting Style | Through Hole | Package / Case | 8PDIP |
| Supplier Device Package | 18-PDIP | Number of Cores/Bus Width | 8 Bit |
Product Info
| Series | PIC12 | On-Chip RAM | No |
| Peripherals | POR, WDT | Manufacturer | Microchip Technology |
| Core Processor | PIC | Number of Timers | 8 |
| RF Family/Standard | PIC12 | Number of Inputs and Type | 5 I/O |
Environmental
| Operating Temperature | -40 to 85 °C | ||
