PIC12F752-I/P
| Manufacturer | |
| Description | MCU 8-bit PIC12 PIC RISC 1.75KB Flash 5V 8-Pin PDIP Tube 1.75KB Flash, 64B RAM, 6 I/O, 8MHz i IC MCU 8BIT 1.75KB FLASH 8DIP PIC12F752-I/P, 8 bit Microcontroller PIC 20MHz 1024words Flash, 64B RAM, 8-Pin PDIP 8-bit Microcontrollers - MCU 1.75KB 64BRAM 6 I/O 8MHz Int Osc 5MIPS IC, MCU, 8BIT, 1.75KB FLASH, 8PDIP PIC microcontroller; SRAM:64B; 20MHz; DIP8; 2÷5.5V Microcontroller 8 Bit DIL-8, PIC12F752-I/P, Microchip Microchip PIC12F 系列 8 bit PIC MCU, 20MHz, 1024 字 ROM 闪存, 64 B RAM, 8针 PDIP封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 900 | Unit Pack | 60 |
| Other Names | PIC12F752IP | Standard Package | Rail / Tube |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85423190 | ||
Electrical
| Speed | 20 MHz | Timer | 1 x 16 bit, 3 x 8 bit |
| Memory | 1.75kB | RAM Size | 64 byte |
| Core Size | 8-Bit | Core Type | PIC |
| Interface | :USB | Clock Rate | 20 MHz |
| Resolution | 10bit | Memory Size | 64 KB |
| Number of I/O | 6 | Voltage Rating | 2 → 5.5 V |
| Watchdog Timer | 1 | Clock Frequency | :20MHz |
| Data Converters | A/D 4x10b, D/A 1x5b | Frequency - Max | 20MHz |
| Number of DAC's | 1 | Oscillator Type | Internal |
| Voltage - Supply | 5 V | Resolution (Bits) | 10bit |
| Number of Channels | 0 | Analog Input:Output | 2 |
| Program Memory Size | 1.75 KB | Program Memory Type | Flash |
| Number of ADCs / DACs | 4 | Number of 8-bit Timers | 2 |
| Voltage - Supply (Min) | 2...5.5V | Frequency (Center/Band) | 16 bit, 8 bit |
| Power Dissipation (Max) | 800 mW | Voltage - Supply (Vcc/Vdd) | 2 V ~ 5.5 V |
Mechanical
| Width | 0.28in | Height | 0.195in |
| Length | 0.4in | Weight | 0.0002 |
| Packaging | Tube | Mounting Type | Through Hole |
| Mounting Style | SMD/SMT | Number of Pins | :8 |
| Package / Case | 8PDIP | Package Cooled | PDIP |
| Material Finish | :- | Package Quantity | 60 |
| Size / Dimension | 0.4 x 0.28 x 0.195in | Number of Positions | 8 |
| Supplier Device Package | 18-PDIP | Number of Cores/Bus Width | 8 Bit |
| Pulse Width Distortion (Max) | 1(10 bit) (CCP) | ||
Product Info
| Spg | 60 | USB | 0 |
| Type | PIC microcontroller | Series | PIC12 |
| On-Chip RAM | 4-chx10-bit | Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| Architecture | RISC | Core Processor | PIC |
| Built in Switch | 8MHz | Number of Units | 1 |
| Number of Timers | 4 | Controller Series | :PIC12F7xx |
| RF Family/Standard | PIC12 | ||
Environmental
| Operating Temperature | -40 to 85 °C | ||
