MCP9800A5T-M/OT
| Manufacturer | |
| Description | Temp Sensor Digital Serial (2-Wire, I2C) 5-Pin SOT-23 T/R IC SENSOR THERMAL 2.7V SOT23-5 Board Mount Temperature Sensors High-Accuracy 12-bit TEMPERATURE SENSOR |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | MCP9800A5T-M/OTCT | Product Category | Board Mount Temperature Sensors |
| Standard Package | Tape & Reel | Factory Pack Quantity | 3000 |
Compliance
| RoHS | Lead free / RoHS Compliant | Automotive | NO |
| Rad Hardened | No | Leadfree Defin | RoHS-conform |
Electrical
| Accuracy | ±3 °C | Interface | Serial (2-Wire, I2C) |
| Output Fan | Yes | Resolution | 12(Max) Bit |
| Output Type | Digital | Sensor Type | Internal |
| Number of Bits | 9 bit to 12 bit | Current - Output | 200 uA |
| Voltage - Supply | 2.7 to 4.5 V | Digital I/O Lines | 2-Wire, I2C, SMBus |
| Voltage - Input (Min) | 2.7 V | Voltage - Supply (Min) | 2.7 V |
| Current - Collector Cutoff (Max) | 0.2 mA | ||
Mechanical
| Packaging | Tape & Reel (TR) | Mounting Type | Surface Mount |
| Package / Case | 5SOT-23 | Package Cooled | SOT-23 |
| Top Termination | 125 °C | Minimum Working Height | -55 °C |
| Supplier Device Package | SOT-23-5 | ||
Product Info
| Function | Temp Sensor | Shutdown | Yes |
| Topology | ADC (Sigma Delta), Register Bank | Technology | CMOS |
| Output Alarm | No | Configuration | Local |
Environmental
| Sensing Temperature | -55°C ~ 125°C | Operating Temperature | -55°C ~ 125°C |
| Switching Temperature | Programmable | Operating Temperature - Junction | 125C |
