MCP6031T-E/MC
| Manufacturer | |
| Description | OP Amp Single GP R-R I/O 5.5V 8-Pin DFN EP T/R Single 1.8V 10kHz Op Amp, E temp IC OPAMP GP 10KHZ RRO 8DFN Operational Amplifiers - Op Amps SNGL 18V 10kHz Op Amp E Temp Precision Amplifiers SNGL 18V 10kHz Op Amp E Temp |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 3300 | Product | Precision Amplifiers |
| Unit Pack | 3300 | Other Names | MCP6031T-E/MCTR |
| Product Category | Operational Amplifiers - Op Amps | Standard Package | Tape & Reel |
| Factory Pack Quantity | 3300 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Gain | 115 dB | PSRR | 70 dB |
| Frequency | 165 nV/sqrt Hz | Slew Rate | 4000@5.5V V/us |
| Output Type | Rail-to-Rail | Input Impedance | 0.0006 pA/sqrt Hz |
| CMRR, PSRR (Typ) | 70 dB | Current - Output | 0.9µA |
| Current - Supply | 0.9 uA | Voltage - Supply | 1.8 V |
| Number of Channels | 1 | Current - Input Bias | 1pA |
| Voltage - Input (Min) | 150µV | Gain Bandwidth Product | 0.01 MHz |
| Rail-to-Rail Operation | Rail to Rail Input/Output | Current - Input Bias (Max) | 0.0001@5.5V uA |
| Current - Output / Channel | 23mA | Input Noise Current Density | 0.0006@5.5V pA/rtHz |
| Input Noise Voltage Density | 165@5.5V nV/rtHz | Voltage - Input Offset (Max) | 0.15@3V mV |
| Voltage - Output Difference (Typ) @ Distance | 115 dB | ||
Mechanical
| Width | 3 mm | Height | 0.88 mm |
| Length | 2 mm | Packaging | Tape & Reel (TR) |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Package / Case | 8DFN EP | Supplier Device Package | 8-DFN (2x3) |
Product Info
| Type | General Purpose Amplifier | Series | MCP6031 |
| Shutdown | No Shutdown | Technology | CMOS |
| Manufacturer | Microchip Technology | Amplifier Type | General Purpose |
| Number of Circuits | 1 | ||
Environmental
| Operating Temperature | -40 to 125 °C | ||
