MCP3422A0-E/SN
| Manufacturer | |
| Description | ADC Single Delta-Sigma 3.75sps 18-bit Serial 8-Pin SOIC N 18-bit delta-sigma ADC, dual channel IC ADC 18BIT3.75SPS 2CH 8-SOIC MCP3422A0-E/SN, 18-Bit Analogue to Digital Converter, Differential, Serial, 8-Pin SOIC Analog to Digital Converters - ADC 18B delta-sigma ADC dual Ch 4sps ANALOG FRONT END 18BIT ADC, DELTA SIGMA, DUAL, 4SPS 18-bitdelta-sigmaADC,dualchannel,4sps,SOIC-8 A/D converter IC 18 Bit SOIC-8, MCP3422A0-E/SN, Microchip Microchip , 18 位 ADC, 差分输入, 串行接口, 8针 SOIC封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 3300 | Unit Pack | 100 |
| Other Names | MCP3422A0ESN | Product Category | Analog to Digital Converters - ADC |
| Standard Package | Rail / Tube | Factory Pack Quantity | 100 |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85423190 | Rad Hardened | No |
Electrical
| Interface | Serial (2-Wire, I2C) | Input Type | Voltage |
| Resolution | 18 Bit | Input Signal | Differential, Single Ended |
| INL/DNL (LSB) | 35ppm FSR | Power - Input | Single |
| Data Interface | I²C, Serial | Input Polarity | Bipolar |
| Number of Bits | 18 | Data Rate (Max) | 0.00375 KSPs |
| Voltage - Rated | �2.048 | Current - Output | :145µA |
| Voltage - Supply | 5 V | Resolution (Bits) | :18bit |
| Voltage Reference | 2.048 V | Number of Channels | 2 Channel |
| Number of Elements | 1 | Sampling Frequency | 3.75 sps |
| Number of ADCs / DACs | 1 | Voltage Supply Source | Single Supply |
| Voltage Supply - Internal | :2.7V to 5.5V | Sampling Rate (Per Second) | 3.75 |
| Differential - Input:Output | Yes | Voltage - Supply Span (Typ) | Not Required V |
| S/N Ratio, ADCs / DACs (db) Typ | Yes | ||
Mechanical
| Width | 3.9mm | Height | 1.25mm |
| Length | 4.9mm | Weight | 0.0002 |
| Packaging | Tube | Termination | :SMD |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :8 | Package / Case | 8SOIC N |
| Package Cooled | SOIC N | Material Finish | :MSL 1 - Unlimited |
| Size / Dimension | 4.9 x 3.9 x 1.25mm | Number of Positions | 8 |
| Supplier Device Package | 8-SOIC N | ||
Product Info
| Architecture | Delta-Sigma | Number of A/D Converters | 2 |
| Number of Inputs and Type | 2 Single-Ended, Bipolar; 2 Differential, Bipolar | ||
Environmental
| Operating Temperature | -40°C ~ 125°C | ||
